LiDAR Sensor
LiDAR Sensor
The P1500 is a high-precision, long-range, lightweight airborne LiDAR scanning device featuring a 100-degree field of view, which allows for extensive coverage during scans. It incorporates a fiber laser, an optical scanning system module, and a high-precision ultra-fast data acquisition system, enabling the rapid collection of high-precision, high-density laser point cloud data. This device excels in precise 3D parameter reconstruction of target environments and is proficient in generating vector map data, 3D geographic data, and street view data. Its applications include road surveying, topographic mapping, urban area surveys, traffic asset inspections, landscaping surveys, and 3D digital city projects.
Basic parameter
Parameters P1500-Mini P1500
Laser Pulse Repetition Rate 100~2000 kHz
Maximum Number of Detected Echoes per Pulse 5
Detection Wavelength 1550nm
Beam Divergence Angle 0.4 mrad 0.3 mrad
Echo Signal Intensity 16 bit
Scanning Angle 110°
Number of Scan Lines 50~300
Minimum Measurement Distance ≤2 m ≤2 m
Maximum Measurement Distance
@ 20% Reflectance
100 kHz:450 m
200kHz:300m
250 kHz:280 m
400kHz:200 m
100 kHz:750 m
200kHz:500m
250 kHz:480 m
400kHz:300 m
600kHz:200m
Maximum Measurement Distance
@ 60% Reflectance
100 kHz:900 m
200kHz:500 m
250 kHz:350 m
400kHz:250m
100 kHz:1500 m
200kHz:700m
250 kHz:540 m
400kHz:330 m
600kHz:210m
Measurement Accuracy ±15 mm
Repeatability ±5 mm
Minimum Step Angle 0.066°
Weight 1.5 kg 2.4 kg
Housing Material Aluminum Alloy
Internal Storage 512 GB SSD
Data Interface LAN
Time Synchronization Real-time timestamping for scanning data
Protection Rating IP64
